碳约束下基于双重博弈的电力零售商售电价格决策优化

doi:10.11930/j.issn.1004-9649.202309065

中国电力 ›› 2024, Vol. 57 ›› Issue (5): 126-136.DOI: 10.11930/j.issn.1004-9649.202309065

• 新型能源体系下电碳协同市场机制及优化运行 • 上一篇下一篇

碳约束下基于双重博弈的电力零售商售电价格决策优化

李方姝(), 余昆(), 陈星莺(), 华昊辰()

河海大学能源与电气学院，江苏南京　210098

收稿日期:2023-09-14 接受日期:2023-12-14 出版日期:2024-05-28 发布日期:2024-05-16
作者简介:李方姝（1999—），女，硕士研究生，从事电力市场与经济研究，E-mail：211606010132@hhu.edu.cn
余昆（1978—），男，博士，教授，从事智能配电网自愈控制与优化调度、用能系统高效运行与能源经济、用能互联网研究，E-mail：kunyu@hhu.edu.cn
陈星莺（1964—），女，博士，教授，从事配用电系统与电力市场、能源管控与能源经济研究，E-mail：xychen@hhu.edu.cn
华昊辰（1988—），男，通信作者，博士，教授，从事需求侧灵活资源调度、微网建模与控制、电力市场与电力经济研究，E-mail：huahc16@tsinghua.org.cn
基金资助:
国家自然科学基金资助项目（与电网友好互动的大规模楼宇群综合能源系统协同优化运行，U22B20112）。

Price Decision Optimization for Electricity Retailers Based on Dual Game under Carbon Constraints

Fangshu LI(), Kun YU(), Xingying CHEN(), Haochen HUA()

College of Energy and Electrical Engineering, Hohai University, Nanjing 210098, China

Received:2023-09-14 Accepted:2023-12-14 Online:2024-05-28 Published:2024-05-16
Supported by:
This work is supported by National Natural Science Foundation of China (Coordinated Optimal Operation of Integrated Energy System for Large-Scale Building Clusters Considering Friendly Interaction with Power Grid, No.U22B20112).

摘要/Abstract

摘要：

在碳约束下，市场中的多零售商竞争售电和多用户购电给电力零售商制定售电价格提高自身利润带来了挑战。为解决零售商售电价格制定的问题，提出了在碳约束条件下多电力零售商竞争售电和多用户购电的双重博弈价格决策优化模型。首先，建立各市场参与者的决策模型。其次，建立并描述电力零售商的双重博弈架构，其中，各电力零售商间构成非合作博弈，各零售商与各用户间构成主从博弈。然后，采用循环迭代嵌套IPOPT求解器的方法求解零售商的双重博弈问题。最后，通过仿真算例对所提模型进行验证分析。仿真结果表明，通过所提模型寻优合理的售电价格可以实现各零售商自身售电利润的最大化，同时用户也能通过博弈模型得到最优的购电策略，以提升用电综合满意度。

关键词: 电力零售商, 双重博弈, 碳约束, 价格决策, 需求响应

Abstract:

Under carbon constraints, multiple retailers competing for sale of electricity and multiple users purchasing electricity in the market bring challenges to electricity retailers in setting their selling price to increase their own profits. Thereby, a dual game price decision optimization model for multiple electricity retailers competing for sale of electricity and multiple users purchasing electricity is proposed to address the issue of retail electricity pricing under carbon constraints. Firstly, a decision-making model for each market participant is established. Secondly, a dual game framework is established for electricity retailers, in which non-cooperative games are formed among electricity retailers, and master-slave games are formed between retailers and users. And then, the loop nested solver IPOPT is used to solve the dual game problem of retailers. Finally, the proposed model is validated and analyzed through simulation examples. The simulation shows that the retailers can realize their profit maximization through the proposed model to optimize reasonable electricity selling price, and at the same time the users can obtain the optimal electricity purchase strategy through the game model to improve their comprehensive satisfaction of electricity consumption.

Key words: electricity retailers, dual game, carbon constraints, price decision, demand response

李方姝, 余昆, 陈星莺, 华昊辰. 碳约束下基于双重博弈的电力零售商售电价格决策优化[J]. 中国电力, 2024, 57(5): 126-136.

Fangshu LI, Kun YU, Xingying CHEN, Haochen HUA. Price Decision Optimization for Electricity Retailers Based on Dual Game under Carbon Constraints[J]. Electric Power, 2024, 57(5): 126-136.

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.electricpower.com.cn/CN/10.11930/j.issn.1004-9649.202309065

https://www.electricpower.com.cn/CN/Y2024/V57/I5/126

图/表 13

参考文献 29

1	ZENG H B, SHAO B L, DAI H B, et al. Incentive-based demand response strategies for natural gas considering carbon emissions and load volatility[J]. Applied Energy, 2023, 348, 121541. DOI
2	HUA H C, SHI J B, CHEN X Y, et al. Carbon emission flow based energy routing strategy in energy Internet[J]. IEEE Transactions on Industrial Informatics, 2024, 20 (3): 3974- 3985.
3	GU H F, LI Y, YU J, et al. Bi-level optimal low-carbon economic dispatch for an industrial park with consideration of multi-energy price incentives[J]. Applied Energy, 2020, 262, 114276. DOI
4	HUA H C, CHEN X Y, GAN L, et al. A demand side joint electricity and carbon trading mechanism[J]. IEEE Transactions on Industrial Cyber-Physical Systems, 2024, 2, 14- 25.
5	JAVANMARD B, TABRIZIAN M, ANSARIAN M, et al. Energy management of multi-microgrids based on game theory approach in the presence of demand response programs, energy storage systems and renewable energy resources[J]. Journal of Energy Storage, 2021, 42, 102971. DOI
6	HONG Q Y, MENG F L, LIU J, et al. A bilevel game-theoretic decision-making framework for strategic retailers in both local and wholesale electricity markets[J]. Applied Energy, 2023, 330, 120311. DOI
7	潘虹锦, 高红均, 杨艳红, 等. 基于主从博弈的售电商多元零售套餐设计与多级市场购电策略[J]. 中国电机工程学报, 2022, 42 (13): 4785- 4800. DOI
	PAN Hongjin, GAO Hongjun, YANG Yanhong, et al. Multi-type retail packages design and multi-level market power purchase strategy for electricity retailers based on master-slave game[J]. Proceedings of the CSEE, 2022, 42 (13): 4785- 4800. DOI
8	华昊辰, 李宇童, 王同贺, 等. 一种基于混合随机H₂/H_∞方法的能源互联网边缘计算系统控制策略[J]. 中国电机工程学报, 2020, 40 (21): 6875- 6885. DOI
	HUA Haochen, LI Yutong, WANG Tonghe, et al. A novel stochastic mixed H₂/H_∞ control strategy for energy internet edge computing system[J]. Proceedings of the CSEE, 2020, 40 (21): 6875- 6885. DOI
9	张帅, 裴玮, 马腾飞, 等. 考虑马尔可夫决策的产消者P2P电能交易非合作博弈模型[J]. 电力系统自动化, 2023, 47 (13): 18- 27. DOI
	ZHANG Shuai, PEI Wei, MA Tengfei, et al. Non-cooperative game model of prosumer P2P electricity trading considering Markov decision[J]. Automation of Electric Power Systems, 2023, 47 (13): 18- 27. DOI
10	张旭东, 李飞, 刘迪, 等. 基于CNN的产消群需求响应滚动优化策略[J]. 中国电力, 2021, 54 (2): 78- 89.
	ZHANG Xudong, LI Fei, LIU Di, et al. CNN-based rolling optimization strategy for prosumer group in demand response[J]. Electric Power, 2021, 54 (2): 78- 89.
11	郭昆健, 高赐威, 林国营, 等. 现货市场环境下售电商激励型需求响应优化策略[J]. 电力系统自动化, 2020, 44 (15): 28- 35. DOI
	GUO Kunjian, GAO Ciwei, LIN Guoying, et al. Optimization strategy of incentive based demand response for electricity retailer in spot market environment[J]. Automation of Electric Power Systems, 2020, 44 (15): 28- 35. DOI
12	詹祥澎, 杨军, 王昕妍, 等. 考虑实时市场联动的电力零售商鲁棒定价策略[J]. 电网技术, 2022, 46 (6): 2141- 2153.
	ZHAN Xiangpeng, YANG Jun, WANG Xinyan, et al. Robust pricing strategy of power retailer considering linkage of real-time market[J]. Power System Technology, 2022, 46 (6): 2141- 2153.
13	ZHU C P, FAN R G, LIN J C. The impact of renewable portfolio standard on retail electricity market: a system dynamics model of tripartite evolutionary game[J]. Energy Policy, 2020, 136, 111072. DOI
14	SUN B, LI M Z, WANG F, et al. An incentive mechanism to promote residential renewable energy consumption in China's electricity retail market: a two-level Stackelberg game approach[J]. Energy, 2023, 269, 126861. DOI
15	DONG J, JIANG Y Z, LIU D R, et al. Promoting dynamic pricing implementation considering policy incentives and electricity retailers' behaviors: an evolutionary game model based on prospect theory[J]. Energy Policy, 2022, 167, 113059. DOI
16	李雅婷, 唐家俊, 张思, 等. 考虑多重不确定性因素的售电公司购售电决策模型[J]. 电力系统自动化, 2022, 46 (7): 33- 41.
	LI Yating, TANG Jiajun, ZHANG Si, et al. Decision-making model of electricity procurement and sale for electricity retailers considering multiple uncertain factors[J]. Automation of Electric Power Systems, 2022, 46 (7): 33- 41.
17	林国营, 卢世祥, 郭昆健, 等. 基于主从博弈的电网公司需求响应补贴定价机制[J]. 电力系统自动化, 2020, 44 (10): 59- 67. DOI
	LIN Guoying, LU Shixiang, GUO Kunjian, et al. Stackelberg game based incentive pricing mechanism of demand response for power grid corporations[J]. Automation of Electric Power Systems, 2020, 44 (10): 59- 67. DOI
18	张婕, 孙伟卿, 刘唯. 考虑需求响应收益的售电商实时电价决策模型[J]. 电网技术, 2022, 46 (2): 492- 504. DOI
	ZHANG Jie, SUN Weiqing, LIU Wei. Real time pricing considering demand response revenue of electricity sellers[J]. Power System Technology, 2022, 46 (2): 492- 504. DOI
19	YAN Q Y, LIN H Y, ZHANG M J, et al. Two-stage flexible power sales optimization for electricity retailers considering demand response strategies of multi-type users[J]. International Journal of Electrical Power & Energy Systems, 2022, 137, 107031.
20	高赐威, 曹家诚, 吕冉, 等. 基于主从博弈的虚拟电厂内部购售电价格制定方法[J]. 电力需求侧管理, 2021, 23 (6): 8- 14. DOI
	GAO Ciwei, CAO Jiacheng, LYU Ran, et al. Method for determining the internal price of virtual power plant based on stackelberg game theory[J]. Power Demand Side Management, 2021, 23 (6): 8- 14. DOI
21	尹龙, 刘继春, 高红均, 等. 考虑多种用户价格机制下的综合型能源售电公司购电竞价策略[J]. 电网技术, 2018, 42 (1): 88- 97. DOI
	YIN Long, LIU Jichun, GAO Hongjun, et al. Study on bidding strategy of comprehensive power retailer under multiple user-price mechanisms[J]. Power System Technology, 2018, 42 (1): 88- 97. DOI
22	JU L W, WU J, LIN H Y, et al. Robust purchase and sale transactions optimization strategy for electricity retailers with energy storage system considering two-stage demand response[J]. Applied Energy, 2020, 271, 115155. DOI
23	戴尚文, 张利, 刘宁宁, 等. 考虑可再生能源消纳责任的售电公司购电决策分析[J]. 中国电力, 2021, 54 (9): 156- 164.
	DAI Shangwen, ZHANG Li, LIU Ningning, et al. Energy purchasing strategy of electricity retailer considering the responsibility of renewable energy consumption[J]. Electric Power, 2021, 54 (9): 156- 164.
24	LIU D, QIN Z M, HUA H C, et al. , Incremental incentive mechanism design for diversified consumers in demand response[J]. Applied Energy, 2023, 329, 120240. DOI
25	李姚旺, 张宁, 杜尔顺, 等. 基于碳排放流的电力系统低碳需求响应机制研究及效益分析[J]. 中国电机工程学报, 2022, 42 (8): 2830- 2842. DOI
	LI Yaowang, ZHANG Ning, DU Ershun, et al. Mechanism study and benefit analysis on power system low carbon demand response based on carbon emission flow[J]. Proceedings of the CSEE, 2022, 42 (8): 2830- 2842. DOI
26	LI P, WANG H, ZHANG B S. A distributed online pricing strategy for demand response programs[J]. IEEE Transactions on Smart Grid, 2019, 10 (1): 350- 360. DOI
27	胡鹏, 艾欣, 张朔, 等. 基于需求响应的分时电价主从博弈建模与仿真研究[J]. 电网技术, 2020, 44 (2): 585- 592. DOI
	HU Peng, AI Xin, ZHANG Shuo, et al. Modelling and simulation study of TOU stackelberg game based on demand response[J]. Power System Technology, 2020, 44 (2): 585- 592. DOI
28	李鹏, 吴迪凡, 李雨薇, 等. 基于综合需求响应和主从博弈的多微网综合能源系统优化调度策略[J]. 中国电机工程学报, 2021, 41 (4): 1307- 1321, 1538. DOI
	LI Peng, WU Difan, LI Yuwei, et al. Optimal dispatch of multi-microgrids integrated energy system based on integrated demand response and stackelberg game[J]. Proceedings of the CSEE, 2021, 41 (4): 1307- 1321, 1538. DOI
29	李飞, 李咸善, 鲁明芳, 等. 计及配额考核约束的发电商与大用户直购电博弈优化模型[J]. 高电压技术, 2023, 49 (1): 128- 137. DOI
	LI Fei, LI Xianshan, LU Mingfang, et al. Game optimization model of direct power purchase between power suppliers and large consumers with RPS assessment constrains[J]. High Voltage Engineering, 2023, 49 (1): 128- 137. DOI

用户	$ {\alpha _m} $	$ {\beta _m} $
1	0.0005	0.15
2	0.0015	0.16
3	0.0010	0.15
4	0.0013	0.12

用户	$ {\alpha _m} $	$ {\beta _m} $
1	0.0005	0.15
2	0.0015	0.16
3	0.0010	0.15
4	0.0013	0.12

零售商		数值
火电零售商1 $ {\bar q _{{\rm g},1}} $/(MW·h)		1400
火电零售商2 $ {\bar q _{{\rm g},2}} $/(MW·h)		1350
火电零售商3 $ {\bar q _{{\rm g},3}} $/(MW·h)		1240
火电零售商4 $ {\bar q _{{\rm g},4}} $/(MW·h)		1110
绿电零售商1 $ {\bar q _{{\rm f},1}} $/(MW·h)		1250
绿电零售商2 $ {\bar q _{{\rm f},2}} $/(MW·h)		1280

零售商		数值
火电零售商1 $ {\bar q _{{\rm g},1}} $/(MW·h)		1400
火电零售商2 $ {\bar q _{{\rm g},2}} $/(MW·h)		1350
火电零售商3 $ {\bar q _{{\rm g},3}} $/(MW·h)		1240
火电零售商4 $ {\bar q _{{\rm g},4}} $/(MW·h)		1110
绿电零售商1 $ {\bar q _{{\rm f},1}} $/(MW·h)		1250
绿电零售商2 $ {\bar q _{{\rm f},2}} $/(MW·h)		1280

参数		数值
火电零售商购火电的价格 $ {p_{\rm g}} $/(元·(MW·h)^–1)		37
绿电零售商购绿电的价格 $ {p_{\rm f}} $/(元·(MW·h)^–1)		45
碳排放权价格 $ {p_{\rm c}} $/(元·t^–1)		40
碳配额比例 $ \lambda $		0.4
电力零售商价格调整步长 $ \eta $		0.01

碳约束下基于双重博弈的电力零售商售电价格决策优化

Price Decision Optimization for Electricity Retailers Based on Dual Game under Carbon Constraints

RichHTML

PDF (PC)

可视化

摘要/Abstract

引用本文

使用本文

图/表 13

参考文献 29

相关文章 15

编辑推荐

Metrics

零售商	时段	售电价格/(元·(MW·h)^–1)
零售商	时段	用户1	用户2	用户3	用户4
火电零售商1	谷	25.634	24.446	25.439	22.891
	平	55.210	59.132	56.486	55.519
	峰	114.313	110.709	109.301	117.410
火电零售商2	谷	23.916	23.736	22.573	20.027
	平	54.914	56.818	57.213	56.165
	峰	115.800	110.436	112.548	116.043
火电零售商3	谷	24.786	25.327	22.024	23.623
	平	55.148	52.726	52.759	55.312
	峰	117.235	115.564	110.964	112.495
火电零售商4	谷	27.113	25.453	24.123	24.692
	平	50.525	54.947	52.910	55.310
	峰	118.347	116.419	118.418	118.410
绿电零售商1	谷	54.136	55.684	55.626	54.129
	平	101.305	100.417	96.340	99.193
	峰	148.423	153.039	150.215	149.945
绿电零售商2	谷	55.197	52.419	53.745	54.402
	平	97.037	96.510	100.419	101.329
	峰	148.019	150.645	153.567	151.043

用户	需求响应前	需求响应后
1	167031	162162
2	159953	155399
3	163533	158881
4	165517	160697
