基于压缩开关候选集合的分布鲁棒配电网重构方法

doi:10.11930/j.issn.1004-9649.202403022

中国电力 ›› 2024, Vol. 57 ›› Issue (10): 12-24, 35.DOI: 10.11930/j.issn.1004-9649.202403022

• 面向现代智慧配电网的二次系统规划 • 上一篇下一篇

基于压缩开关候选集合的分布鲁棒配电网重构方法

杜浩程¹(), 李世龙²^,⁴(), 巨云涛³(), 张晋奇⁵()

1. 中国农业大学信息与电气工程学院，北京　100083
2. 电力物联网四川省重点实验室，四川成都　610095
3. 北方工业大学电气与控制工程学院，北京　100144
4. 国网四川省电力公司电力科学研究院，四川成都　610095
5. 山西省能源互联网研究院，山西太原　030000

收稿日期:2024-03-06 出版日期:2024-10-28 发布日期:2024-10-25
作者简介:杜浩程（1995—），男，硕士，从事配电网运行与优化技术研究，E-mail：595523633@qq.com
李世龙（1989—），男，博士，工程师，从事配电网运行与控制技术研究，E-mail：981163632@qq.com
巨云涛（1985—），男，通信作者，教授，从事高比例可再生能源系统的分布自律-集中协同的稳定分析与优化调控技术、分布式协同能量管理系统研究，E-mail：juyuntaomail@163.com
基金资助:
电力物联网四川省重点实验室开放课题项目（PIT-F-202205）。

A Distributional Robust Distribution Network Reconfiguration Method Based on Compressed Switch Candidate Set

Haocheng DU¹(), Shilong LI²^,⁴(), Yuntao JU³(), Jinqi ZHANG⁵()

1. College of Information and Electrical Engineering, China Agricultural University, Beijing 100083, China
2. Power Internet of Things Key Laboratory of Sichuan Province, Chengdu 610095, China
3. School of Electrical and Control Engineering, North China University of Technology, Beijing 100144, China
4. State Grid Sichuan Electric Power Research Institute, Chengdu 610095, China
5. Shanxi Energy Internet Research Institute, Taiyuan 030000, China

Received:2024-03-06 Online:2024-10-28 Published:2024-10-25
Supported by:
This work is supported by the Opening Fund of Power Internet of Things Key Laboratory of Sichuan Province (No.PIT-F-202205).

摘要/Abstract

摘要：

在大规模多时刻配电网重构（distribution network reconfiguration，DNR）问题中，大量待优化的开关严重降低了配电网重构的求解效率。针对此问题，提出了一种压缩开关候选集合的分布鲁棒配电网重构模型，该模型分为2个阶段，第1阶段以最小化系统有功网损为目标函数，使用最优匹配回路流法压缩开关候选集合，第2阶段以最小化取电成本和开关动作成本之和为目标函数，并构建以电源点容量为限值的机会约束，采用基于Wasserstein球的分布鲁棒方法处理分布式电源的不确定性，利用对偶转换方法对目标函数中的最坏情况期望和机会约束进行确定性转换，将模型转化为一个混合整数二阶锥规划问题。最后，对33节点和辽宁盘锦45节点系统进行了数值实验，证明了所提模型能够有效提升计算效率，与鲁棒模型和随机规划模型相比，决策者可以通过改变样本数量和置信度来调整模型的经济性和保守性。

关键词: 配电网重构, 最优匹配回路流, 分布鲁棒优化, Wasserstein球, 机会约束

Abstract:

In the large-scale multi-moment distribution network reconfiguration (DNR) problem, a large number of switches to be optimized seriously reduces the solution efficiency of distribution network reconfiguration. To address this problem, a distributional robust distribution network reconfiguration model based on a compressed switch candidate set was proposed, which was divided into two stages. The first stage took the minimization of active network loss of the system as the objective function and used the optimal matching loop flow method to compress the switch candidate set; the second stage took the minimization of the sum of the power purchase cost and the switch action cost as the objective function, constructed the chance constraints on the capacity limits of the power point, and adopted a Wasserstein ball-based distributional robust method to deal with the uncertainty of distributed generation. It transformed the model into a mixed-integer second-order conic planning problem by deterministically transforming the worst-case expectation and chance constraints in the objective function by using a dual transformation method. Finally, numerical experiments were conducted on the 33 node and Liaoning Panjin 45 node systems, which proved that the model proposed in this paper could effectively improve the computational efficiency, and the decision maker could adjust the economy and conservatism of the model by changing the number of samples and the confidence level, compared with the robust model and the stochastic planning model.

Key words: distribution network reconfiguration, optimal matching loop flow, distributional robust optimization, Wasserstein ball, chance constraint

杜浩程, 李世龙, 巨云涛, 张晋奇. 基于压缩开关候选集合的分布鲁棒配电网重构方法[J]. 中国电力, 2024, 57(10): 12-24, 35.

Haocheng DU, Shilong LI, Yuntao JU, Jinqi ZHANG. A Distributional Robust Distribution Network Reconfiguration Method Based on Compressed Switch Candidate Set[J]. Electric Power, 2024, 57(10): 12-24, 35.

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.electricpower.com.cn/CN/10.11930/j.issn.1004-9649.202403022

https://www.electricpower.com.cn/CN/Y2024/V57/I10/12

图/表 19

参考文献 32

1	ZHAN J P, LIU W J, CHUNG C Y, et al. Switch opening and exchange method for stochastic distribution network reconfiguration[J]. IEEE Transactions on Smart Grid, 2020, 11 (4): 2995- 3007. DOI
2	翟鹤峰, 杨明, 赵利刚, 等. 提升分布式电源接纳能力的配电网三相鲁棒动态重构[J]. 电力系统自动化, 2019, 43 (18): 35- 42. DOI
	ZHAI Hefeng, YANG Ming, ZHAO Ligang, et al. Three-phase robust dynamic reconfiguration of distribution network to improve acceptance ability of distributed generator[J]. Automation of Electric Systems, 2019, 43 (18): 35- 42. DOI
3	ZHOU A P, ZHAI H F, YANG M, et al. Three-phase unbalanced distribution network dynamic reconfiguration: a distributionally robust approach[J]. IEEE Transactions on Smart Grid, 2022, 13 (3): 2063- 2074. DOI
4	LI Z C, JAZEBI S, DE LEÓN F. Determination of the optimal switching frequency for distribution system reconfiguration[J]. IEEE Transactions on Power Delivery, 2017, 32 (4): 2060- 2069. DOI
5	赵静翔, 牛焕娜, 王钰竹. 基于信息熵时段划分的主动配电网动态重构[J]. 电网技术, 2017, 41 (2): 402- 408.
	ZHAO Jingxiang, NIU Huanna, WANG Yuzhu. Dynamic reconfiguration of active distribution network based on information entropy of time intervals[J]. Power System Technology, 2017, 41 (2): 402- 408.
6	WANG Q F, GUAN Y P, WANG J H. A chance-constrained two-stage stochastic program for unit commitment with uncertain wind power output[C]//2012 IEEE Power and Energy Society General Meeting. San Diego, CA, USA. IEEE, 2012: 1.
7	AHMED H M A, ELTANTAWY A B, SALAMA M M A. A planning approach for the network configuration of AC-DC hybrid distribution systems[J]. IEEE Transactions on Smart Grid, 2018, 9 (3): 2203- 2213.
8	LEE C, LIU C, MEHROTRA S, et al. Robust distribution network reconfiguration[J]. IEEE Transactions on Smart Grid, 2015, 6 (2): 836- 842. DOI
9	HAGHIGHAT H, ZENG B. Distribution system reconfiguration under uncertain load and renewable generation[J]. IEEE Transactions on Power Systems, 2016, 31 (4): 2666- 2675. DOI
10	LEI S B, HOU Y H, QIU F, et al. Identification of critical switches for integrating renewable distributed generation by dynamic network reconfiguration[J]. IEEE Transactions on Sustainable Energy, 2018, 9 (1): 420- 432. DOI
11	AKRAMI A, DOOSTIZADEH M, AMINIFAR F. Optimal reconfiguration of distribution network using μPMU measurements: a data-driven stochastic robust optimization[J]. IEEE Transactions on Smart Grid, 2020, 11 (1): 420- 428. DOI
12	MAHDAVI M, ALHELOU H H, HESAMZADEH M R. An efficient stochastic reconfiguration model for distribution systems with uncertain loads[J]. IEEE Access, 2022, 10, 10640- 10652. DOI
13	MAHDAVI M, ALHELOU H H, SIANO P, et al. Robust mixed-integer programing model for reconfiguration of distribution feeders under uncertain and variable loads considering capacitor banks, voltage regulators, and protective relays[J]. IEEE Transactions on Industrial Informatics, 2022, 18 (11): 7790- 7803. DOI
14	HAJEBRAHIMI A, KAMWA I, ABDELAZIZ M M A, et al. Scenario-wise distributionally robust optimization for collaborative intermittent resources and electric vehicle aggregator bidding strategy[J]. IEEE Transactions on Power Systems, 2020, 35 (5): 3706- 3718. DOI
15	马望, 高红均, 杨艳红, 等. 融入重构级别快速识别的配电网两阶段优化运行[J]. 中国电机工程学报, 2022, 42 (14): 5154- 5168.
	MA Wang, GAO Hongjun, YANG Yanhong, et al. Two-stage optimal operation for distribution network based on fast identification of reconfiguration level[J]. Proceedings of the CSEE, 2022, 42 (14): 5154- 5168.
16	税月, 刘俊勇, 高红均, 等. 考虑风电不确定性的电气能源系统两阶段分布鲁棒协同调度[J]. 电力系统自动化, 2018, 42 (13): 43- 50, 75. DOI
	SHUI Yue, LIU Junyong, GAO Hongjun, et al. Two-stage distributed robust cooperative dispatch for integrated electricity and natural gas energy systems considering uncertainty of wind power[J]. Automation of Electric Power Systems, 2018, 42 (13): 43- 50, 75. DOI
17	ZHENG W Y, HUANG W J, HILL D J, et al. An adaptive distributionally robust model for three-phase distribution network reconfiguration[J]. IEEE Transactions on Smart Grid, 2021, 12 (2): 1224- 1237. DOI
18	CHEN Y W, GUO Q L, SUN H B, et al. A distributionally robust optimization model for unit commitment based on kullback–leibler divergence[J]. IEEE Transactions on Power Systems, 2018, 33 (5): 5147- 5160. DOI
19	ZHOU A P, YANG M, WANG M Q, et al. A linear programming approximation of distributionally robust chance-constrained dispatch with Wasserstein distance[J]. IEEE Transactions on Power Systems, 2020, 35 (5): 3366- 3377. DOI
20	竺如洁, 韦化, 白晓清. 多源动态最优潮流的分布鲁棒优化方法[J]. 中国电机工程学报, 2020, 40 (11): 3489- 3497.
	ZHU Rujie, WEI Hua, BAI Xiaoqing. Distributionally robust optimization of multi-energy dynamic optimal power flow[J]. Proceedings of the CSEE, 2020, 40 (11): 3489- 3497.
21	曾捷, 童晓阳, 范嘉乐. 计及需求响应不确定性的电-气耦合配网系统动态分布鲁棒优化[J]. 电网技术, 2022, 46 (5): 1877- 1886.
	ZENG Jie, TONG Xiaoyang, FAN Jiale. Dynamic distributionally robust optimization of integrated electric-gas distribution system considering demand response uncertainty[J]. Power System Technology, 2022, 46 (5): 1877- 1886.
22	CHEN Y, WEI W, LIU F, et al. Distributionally robust hydro-thermal-wind economic dispatch[J]. Applied Energy, 2016, 173, 511- 519. DOI
23	WANG Z, BIAN Q Y, XIN H H, et al. A distributionally robust co-ordinated reserve scheduling model considering CVaR-based wind power reserve requirements[J]. IEEE Transactions on Sustainable Energy, 2016, 7 (2): 625- 636. DOI
24	ZHOU Y Z, SHAHIDEHPOUR M, WEI Z N, et al. Distributionally robust co-optimization of energy and reserve for combined distribution networks of power and district heating[J]. IEEE Transactions on Power Systems, 2020, 35 (3): 2388- 2398. DOI
25	WANG XIAOLU, YUEN-MAN PUN, ANTHONY MAN-CHO SO. Moment uncertainty[J]. IEEE Transactions on Signal Processing, 2022, 70, 6216- 6231. DOI
26	HAO B, CAI K Q, FANG Y P, et al. A moment-based distributionally robust optimization model for air traffic flow management[C]//2021 IEEE/AIAA 40th Digital Avionics Systems Conference (DASC). San Antonio, TX, USA. IEEE, 2021: 1-7.
27	ZHU R J, WEI H, BAI X Q. Wasserstein metric based distributionally robust approximate framework for unit commitment[J]. IEEE Transactions on Power Systems, 2019, 34 (4): 2991- 3001. DOI
28	ZHAO C Y, GUAN Y P. Data-driven risk-averse stochastic optimization with Wasserstein metric[J]. Operations Research Letters, 2018, 46 (2): 262- 267. DOI
29	MOHAJERIN ESFAHANI P, KUHN D. Data-driven distributionally robust optimization using the Wasserstein metric: performance guarantees and tractable reformulations[J]. Mathematical Programming, 2018, 171 (1): 115- 166.
30	ZYMLER S, KUHN D, RUSTEM B. Distributionally robust joint chance constraints with second-order moment information[J]. Mathematical Programming, 2013, 137 (1): 167- 198.
31	SHI Z C, LIANG H, HUANG S J, et al. Distributionally robust chance-constrained energy management for islanded microgrids[J]. IEEE Transactions on Smart Grid, 2019, 10 (2): 2234- 2244. DOI
32	蔡智萍, 郭谋发, 魏正峰. 基于BP神经网络的低压配电网生命体触电识别方法研究[J]. 电网技术, 2022, 46 (4): 1614- 1623.
	CAI Zhiping, GUO Moufa, WEI Zhengfeng. Research on recognition method of living body shock in low-voltage distribution network based on BP neural network[J]. Power System Technology, 2022, 46 (4): 1614- 1623.

回路	场景1（12:00）		场景2（20:00）		场景3（04:00）		开关候选集合
回路	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	开关候选集合
1	$ \begin{aligned} & 0.133 + \\& \rm j0.030\end{aligned} $	7-8	$\begin{aligned} & 0.020 +\\ & \rm j0.006 \end{aligned}$	6-7	$ \begin{aligned} &0.048 +\\& \rm j0.012\end{aligned} $	6-7	6-7、7-8、6-26、26-27、30-31、32-33、8-9、11-12、12-22、13-14、14-15
2	$\begin{aligned} & 0.021 - \\ & \rm j0.001\end{aligned} $	26-27	$\begin{aligned} &0.008 - \\ & \rm j0.011\end{aligned} $	6-26	$ \begin{aligned} &0.016 - \\& \rm j0.003 \end{aligned}$	26-27
3	$ \begin{aligned} &0.032 + \\& \rm j0.001\end{aligned} $	32-33	$\begin{aligned} & 0.032 +\\&\rm j0.009\end{aligned} $	30-31	$ \begin{aligned} &0.016 +\\& \rm j0.004\end{aligned} $	30-31
4	$ \begin{aligned} &- 0.066 + \\& \rm j0.026\end{aligned} $	12-22	$ \begin{aligned} &- 0.008 + \\& \rm j0.002\end{aligned} $	11-12	$\begin{aligned} & - 0.020 + \\& \rm j0.018 \end{aligned}$	8-9
5	$ \begin{aligned} &- 0.049 +\\& \rm j0.005\end{aligned} $	13-14	$\begin{aligned} & - 0.014 +\\&\rm j0.021\end{aligned} $	13-14	$ \begin{aligned} &- 0.006 + \\& \rm j0.009\end{aligned} $	14-15

回路	场景1（12:00）		场景2（20:00）		场景3（04:00）		开关候选集合
回路	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	开关候选集合
1	$ \begin{aligned} & 0.133 + \\& \rm j0.030\end{aligned} $	7-8	$\begin{aligned} & 0.020 +\\ & \rm j0.006 \end{aligned}$	6-7	$ \begin{aligned} &0.048 +\\& \rm j0.012\end{aligned} $	6-7	6-7、7-8、6-26、26-27、30-31、32-33、8-9、11-12、12-22、13-14、14-15
2	$\begin{aligned} & 0.021 - \\ & \rm j0.001\end{aligned} $	26-27	$\begin{aligned} &0.008 - \\ & \rm j0.011\end{aligned} $	6-26	$ \begin{aligned} &0.016 - \\& \rm j0.003 \end{aligned}$	26-27
3	$ \begin{aligned} &0.032 + \\& \rm j0.001\end{aligned} $	32-33	$\begin{aligned} & 0.032 +\\&\rm j0.009\end{aligned} $	30-31	$ \begin{aligned} &0.016 +\\& \rm j0.004\end{aligned} $	30-31
4	$ \begin{aligned} &- 0.066 + \\& \rm j0.026\end{aligned} $	12-22	$ \begin{aligned} &- 0.008 + \\& \rm j0.002\end{aligned} $	11-12	$\begin{aligned} & - 0.020 + \\& \rm j0.018 \end{aligned}$	8-9
5	$ \begin{aligned} &- 0.049 +\\& \rm j0.005\end{aligned} $	13-14	$\begin{aligned} & - 0.014 +\\&\rm j0.021\end{aligned} $	13-14	$ \begin{aligned} &- 0.006 + \\& \rm j0.009\end{aligned} $	14-15

回路	场景4（16:00）		场景5（06:00）		开关候选集合
回路	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	开关候选集合
1	$ 0.148 +\rm j0.040 $	6-7	$ 0.030 +\rm j0.008 $	6-7	6-7、26-27、27-28、32-33、30-31、11-12、13-14
2	$ 0.035 -\rm j0.002 $	27-28	$ 0.007 -\rm j0.000 $	26-27
3	$ 0.058 +\rm j0.003 $	32-33	$ 0.012 +\rm j0.000 $	30-31
4	$ - 0.078 +\rm j0.021 $	11-12	$ - 0.016 +\rm j0.004 $	11-12
5	$ - 0.047 +\rm j0.004 $	13-14	$ - 0.004 +\rm j0.009 $	13-14

回路	场景4（16:00）		场景5（06:00）		开关候选集合
回路	最小残留电流 (p.u.)	开关	最小残留电流 (p.u.)	开关	开关候选集合
1	$ 0.148 +\rm j0.040 $	6-7	$ 0.030 +\rm j0.008 $	6-7	6-7、26-27、27-28、32-33、30-31、11-12、13-14
2	$ 0.035 -\rm j0.002 $	27-28	$ 0.007 -\rm j0.000 $	26-27
3	$ 0.058 +\rm j0.003 $	32-33	$ 0.012 +\rm j0.000 $	30-31
4	$ - 0.078 +\rm j0.021 $	11-12	$ - 0.016 +\rm j0.004 $	11-12
5	$ - 0.047 +\rm j0.004 $	13-14	$ - 0.004 +\rm j0.009 $	13-14

方法	成本/ 千元	计算时间/s	打开过的开关
经过压缩	3.8318	923	6-7、11-12、13-14、 26-27、30-31、32-33
未经压缩	3.8318	4002	6-7、11-12、13-14、 26-27、30-31、32-33

基于压缩开关候选集合的分布鲁棒配电网重构方法

A Distributional Robust Distribution Network Reconfiguration Method Based on Compressed Switch Candidate Set

RichHTML

PDF (PC)

可视化

摘要/Abstract

引用本文

使用本文

图/表 19

参考文献 32

相关文章 15

编辑推荐

Metrics

参数	不同优化模型下的成本/千元
参数	RO	DRO	SP	CM
$ \beta = 0.70 $	3.9254	3.8104	3.7886	3.7733
$ \beta = 0.80 $	3.9254	3.8203	3.7886	3.7733
$ \beta = 0.90 $	3.9254	3.8318	3.7886	3.7733
$ \varepsilon = 0.10 $	3.9254	3.8318	3.7943	3.7733
$ \varepsilon = 0.20 $	3.9254	3.8226	3.7871	3.7733
$ \varepsilon = 0.30 $	3.9254	3.8144	3.7854	3.7733

方法	成本/ 元	计算时间/s	打开过的开关
经过压缩	5764.2	1419	4-5、5-6、7-8、 16-17、18-19、19-20、23-26、26-27、18-38
未经压缩	5764.2	3202	4-5、5-6、7-8、 16-17、18-19、19-20、23-26、26-27、18-38

时段	断开的开关
时段	CM	DRO
$ {t_1}\sim {t_7} $	4-5, 5-6, 18-19, 18-38, 26-27	4-5, 5-6, 18-19, 18-38, 26-27
$ {t_8} \sim {t_{10}} $	4-5, 6-7, 18-19, 18-38, 23-26	4-5, 5-6, 18-19, 18-38, 26-27
$ {t_{11}} \sim {t_{13}} $	4-5, 7-8, 18-19, 16-17, 26-27	4-5, 7-8, 18-19, 16-17, 26-27
$ {t_{14}} \sim {t_{24}} $	4-5, 5-6, 19-20, 18-38, 23-26	4-5, 6-7, 19-20, 18-38, 23-26

[1]	翟苏巍, 李银银, 杜凡, 李文云, 潘凯岩, 梁峻恺. 考虑海量分布式能源接入的配电网分布式无功控制策略[J]. 中国电力, 2024, 57(8): 138-144.
[2]	齐彩娟, 陈宝生, 韦冬妮, 杨钊. 考虑主从博弈定价模式的共享储能分布鲁棒优化配置方法研究[J]. 中国电力, 2024, 57(7): 40-53.
[3]	刘志伟, 马悦, 沙志成, 邵云姝, 牛远方, 董晓明, 王成福. 考虑新能源多重相关性的柔性配电网分布鲁棒优化策略[J]. 中国电力, 2024, 57(12): 97-108.
[4]	张颖, 文艳, 季宇, 左娟, 王文博. 基于目标级联法的虚拟电厂日前调频容量计算方法[J]. 中国电力, 2024, 57(1): 82-90.
[5]	齐彩娟, 车彬, 杨燕, 陈宝生. 考虑新能源消纳与储能参与调频的共享储能主从博弈鲁棒定价方法[J]. 中国电力, 2023, 56(8): 26-39.
[6]	姚力, 郑海峰, 单葆国, 谭显东, 许传龙, 徐志成. 基于数据驱动机会约束的发电企业电煤采购及库存优化模型[J]. 中国电力, 2023, 56(6): 176-184.
[7]	于艾清, 丁丽青, 王育飞, 李豪. 基于故障邻接状态的配电网多故障抢修与优化策略[J]. 中国电力, 2023, 56(3): 64-76.
[8]	李强, 王尧, 胡迎迎, 郑晓明, 张琳娜, 荆永明. 考虑碳交易成本的输储多阶段协调规划方法[J]. 中国电力, 2023, 56(12): 199-205.
[9]	冯凯辉, 闫湖, 戴吴珍, 陈健, 刘永亮. 计及能源利用效率的含生物质沼气发电农村能源系统优化运行[J]. 中国电力, 2022, 55(7): 172-178.
[10]	吴强, 韩俊, 金颋, 蔡超, 孟诗语, 殷俊平. 冷热电联供型孤岛微电网环保经济调度模型[J]. 中国电力, 2021, 54(12): 137-142.
[11]	沈依婷, 张菁, 武鹏, 柳璐, 杨建林. 含电动汽车的配电网双重不确定性网架规划方法[J]. 中国电力, 2020, 53(4): 139-146.
[12]	赵楠, 王蓓蓓. 计及多类型需求响应资源的配电网分布式电源优化配置[J]. 中国电力, 2019, 52(11): 51-59,67.
[13]	高元海，王淳. 基于八种智能算法的配电网络重构计算平台及其性能[J]. 中国电力, 2015, 48(8): 53-60.
[14]	张新松, 顾菊平, 郭晓丽. 基于离散概率潮流的大风电接入后的电网规划[J]. 中国电力, 2014, 47(4): 128-133.
[15]	王海潮, 周玲, 丁晓群, 陆晨. 计及不确定性的配电网模糊优化重构[J]. 中国电力, 2014, 47(2): 156-160.

参数	不同优化模型下的成本/千元
参数	RO	DRO	SP	CM
$ \beta = 0.70 $	5.8426	5.7403	5.7250	5.6888
$ \beta = 0.80 $	5.8426	5.7529	5.7250	5.6888
$ \beta = 0.90 $	5.8426	5.7642	5.7250	5.6888
$ \varepsilon = 0.10 $	5.8426	5.7642	5.7219	5.6888
$ \varepsilon = 0.20 $	5.8426	5.7503	5.7142	5.6888
$ \varepsilon = 0.30 $	5.8426	5.7479	5.7018	5.6888

参数	不同优化模型下的成本/千元
参数	RO	DRO	SP	CM
$ \beta = 0.70 $	5.8426	5.7403	5.7250	5.6888
$ \beta = 0.80 $	5.8426	5.7529	5.7250	5.6888
$ \beta = 0.90 $	5.8426	5.7642	5.7250	5.6888
$ \varepsilon = 0.10 $	5.8426	5.7642	5.7219	5.6888
$ \varepsilon = 0.20 $	5.8426	5.7503	5.7142	5.6888
$ \varepsilon = 0.30 $	5.8426	5.7479	5.7018	5.6888

样本容量		计算时间/s
100		239
300		232
500		242
700		245

样本容量		计算时间/s
100		239
300		232
500		242
700		245
