充电用能约束下工业园区负荷管控的随机优化策略

doi:10.11930/j.issn.1004-9649.202311142

摘要/Abstract

摘要：

为解决工业园区微电网在能源短缺情况下的负荷管理问题，提出一种管理用户特定负荷的新方法。首先，将用户特定负荷管理定义为一个随机预测模型控制问题，对光伏和用户电力需求进行预测建模。然后，结合两阶段随机规划和近似动态规划对其进行求解。最后，在模拟用户对负荷管理响应的环境中，通过2种控制器测试了替代解决方案的有效性。结果表明，即使没有完整的用户响应模型，控制器使用预测模型进行负荷管理也可以显著提高电力可用性和用户的消费效益。

关键词: 工业园区, 负荷管理, 随机预测模型, 两阶段随机规划, 近似动态规划

Abstract:

In order to solve the load management problem of industrial park microgrids in the event of energy shortage, this paper proposes a new method for managing user-specific loads. By defining the user-specific load management as a stochastic predictive model control problem, this method firstly establishes prediction models for photovoltaic and users’ power demand, and then solve them using two-stage stochastic programming and approximate dynamic programming. Finally, the effectiveness of the alternative solutions is tested through two controllers in an environment in which user response to the load management is simulated. The results indicate that even if the controller does not have a complete model of user response, the predictive models used for scheduling the load management can significantly improve the power availability and user consumption efficiency.

Key words: industrial park, load management, random prediction model, two stage stochastic programming, approximate dynamic programming

茹传红, 卢姬, 秦建, 张军达, 常俊晓, 蒋贝妮. 充电用能约束下工业园区负荷管控的随机优化策略[J]. 中国电力, 2025, 58(8): 130-138.

RU Chuanhong, LU Ji, QIN Jian, ZHANG Junda, CHANG Junxiao, JIANG Beini. Stochastic Optimization Strategy for Load Management of Industrial Park Under Energy Constraints[J]. Electric Power, 2025, 58(8): 130-138.

导出引用管理器 EndNote|Ris|BibTeX

链接本文: https://www.electricpower.com.cn/CN/10.11930/j.issn.1004-9649.202311142

https://www.electricpower.com.cn/CN/Y2025/V58/I8/130

图/表 5

参考文献 21

1	王大兴, 宁妍, 汪敬培等. 构建新型电力系统背景下的微电网鲁棒简化建模[J]. 中国电力, 2024, 57 (1): 148- 157.
	WANG Daxing, NING Yan, WANG Jingpei, et al. Robust simplified modeling of microgrid in the context of constructing new power systems[J]. Electric Power, 2024, 57 (1): 148- 157.
2	赵军, 张敏, 张世锋, 等. 计及碳交易和新能源不确定性的多微电网合作运行优化策略[J]. 中国电力, 2023, 56 (5): 62- 71.
	ZHAO Jun, ZHANG Min, ZHANG Shifeng, et al. Optimization strategy of multi-microgrid cooperative operation considering carbon trading and renewable energy uncertainties[J]. Electric Power, 2023, 56 (5): 62- 71.
3	贾宏刚, 王主丁, 岳园园, 等. 微电网调度模型的寻优性能与求解效率改进优化[J]. 中国电力, 2023, 56 (6): 107- 113, 131.
	JIA Honggang, WANG Zhuding, YUE Yuanyuan, et al. Optimization performance and efficiency improvement of microgrid scheduling model[J]. Electric Power, 2023, 56 (6): 107- 113, 131.
4	魏震波, 张芷琪, 李银江, 等. 多主体合作模式下微电网规划运行一体化模型[J]. 电力建设, 2024, 45 (10): 47- 58.
	WEI Zhenbo, ZHANG Zhiqi, LI Yinjiang, et al. An integrated model of microgrid planning and operation under A multi-subject cooperation model[J]. Electric Power Construction, 2024, 45 (10): 47- 58.
5	陈勃旭, 崔炜, 陈宇, 等. 分布储能直流微电网中多储能荷电均衡控制策略[J]. 电力系统保护与控制, 2023, 51 (24): 111- 120.
	CHEN Boxu, CUI Wei, CHEN Yu, et al. Charge balance control strategy for multiple energy storage in a distributed energy storage DC microgrid[J]. Power System Protection and Control, 2023, 51 (24): 111- 120.
6	刘任, 刘洋, 许立雄, 等. 计及分布式需求响应的多微电网系统协同优化策略[J]. 电力建设, 2023, 44 (5): 72- 83.
	LIU Ren, LIU Yang, XU Lixiong, et al. Multi-microgrid system collaborative optimization strategy considering distributed demand response[J]. Electric Power Construction, 2023, 44 (5): 72- 83.
7	宋扬, 石勇, 刘宝泉, 等. 基于改进麻雀搜索算法的机场微电网优化调度策略[J]. 电力科学与技术学报, 2022, 37 (3): 33- 40.
	SONG Yang, SHI Yong, LIU Baoquan, et al. Optimal dispatching strategy of airport microgrid based on the improved sparrow search algorithm[J]. Journal of Electric Power Science and Technology, 2022, 37 (3): 33- 40.
8	李现宝, 张可. 基于改进和声搜索算法的微电网优化调度研究[J]. 东北电力大学学报, 2022, 42 (5): 83- 89.
	LI Xianbao, ZHANG Ke. Research on optimal dispatching of microgrid based on improved harmony search algorithm[J]. Journal of Northeast Electric Power University, 2022, 42 (5): 83- 89.
9	景皓, 贾伯岩, 卢志刚, 等. 考虑可平移负荷管理的主动配电网故障恢复方法[J]. 智慧电力, 2020, 48 (11): 48- 54, 61.
	JING Hao, JIA Boyan, LU Zhigang, et al. Fault recovery method for active distribution network considering shiftable load management[J]. Smart Power, 2020, 48 (11): 48- 54, 61.
10	赵梓潼, 顾兵. 需求响应下基于电动汽车负荷聚合商的充放电电价与时段研究[J]. 东北电力大学学报, 2023, 43 (6): 79- 86.
	ZHAO Zitong, GU Bing. Research on charging and discharging price and time period based on electric vehicle load aggregator under demand response[J]. Journal of Northeast Electric Power University, 2023, 43 (6): 79- 86.
11	刘国伟, 马楠, 邓浩, 等. 考虑需求侧管理和网络重构的配电网新能源承载能力评估[J]. 中国电力, 2023, 56 (8): 186- 192.
	LIU Guowei, MA Nan, DENG Hao, et al. Assessment of new energy supportability of distribution network considering demand side management and network reconfiguration[J]. Electric Power, 2023, 56 (8): 186- 192.
12	陈海鹏, 周越豪, 赵畅, 等. 考虑高载能负荷参与的多时间尺度风电消纳调度[J]. 东北电力大学学报, 2022, 42 (6): 39- 51.
	CHEN Haipeng, ZHOU Yuehao, ZHAO Chang, et al. Multi-time scale wind power consumption scheduling with high energy load participation is considered[J]. Journal of Northeast Electric Power University, 2022, 42 (6): 39- 51.
13	潘忠志, 孔宁, 王燕涛. 改进新能源消纳的配电网资源优化配置研究[J]. 东北电力大学学报, 2023, 43 (6): 71- 78.
	PAN Zhongzhi, KONG Ning, WANG Yantao. Joint optimal allocation method of energy-load-storage in power supply area to improve new energy consumption capacity[J]. Journal of Northeast Electric Power University, 2023, 43 (6): 71- 78.
14	孙毅, 周晋宇, 李彬, 等. 基于启动时间延迟的家庭负荷管理优化策略[J]. 电力自动化设备, 2017, 37 (2): 83- 89.
	SUN Yi, ZHOU Jinyu, LI Bin, et al. Optimization strategy based on start-time delay for domestic load management[J]. Electric Power Automation Equipment, 2017, 37 (2): 83- 89.
15	魏景东, 张耀, 王建学, 等. 考虑综合需求响应的工业园区负荷管理方法[J]. 电力需求侧管理, 2021, 23 (1): 25- 29.
	WEI Jingdong, ZHANG Yao, WANG Jianxue, et al. Industrial park load management method considering integrated demand response[J]. Power Demand Side Management, 2021, 23 (1): 25- 29.
16	于娜, 于乐征, 李国庆. 智能电网环境下基于多代理的商业用户可控负荷管理策略[J]. 电力系统自动化, 2015, 39 (17): 89- 95,102.
	YU Na, YU Lezheng, LI Guoqing. Controllable load management strategy for commercial users based on multi-agent in smart grid environment[J]. Automation of Electric Power Systems, 2015, 39 (17): 89- 95,102.
17	李佩杰, 万海涛, 赵晓慧, 等. 定制化求解机组组合混合整数线性规划模型的固定—推断法[J]. 电力系统保护与控制, 2023, 51 (2): 11- 21.
	LI Peijie, WAN Haitao, ZHAO Xiaohui, et al. A customized fix and implicate method for mixed integer linear programming models of unit commitment problems[J]. Power System Protection and Control, 2023, 51 (2): 11- 21.
18	张琳娜, 乐健, 李昊炅. 基于混合整数线性规划的含ZIP负荷有源配电网重构方法[J]. 电力系统保护与控制, 2022, 50 (8): 25- 32.
	ZHANG Linna, LE Jian, LI Haojiong. Reconfiguration method of an active distribution network with a ZIP load model based on mixed integer linear programming[J]. Power System Protection and Control, 2022, 50 (8): 25- 32.
19	李娟, 王玲, 孙康杰, 等. 考虑风电不确定性和有功无功联合调整的两阶段优化调度[J]. 东北电力大学学报, 2023, 43 (3): 72- 81.
	LI Juan, WANG Ling, SUN Kangjie, et al. Two-stage optimal dispatch considering uncertainty of wind power and joint regulaiton of active and reactive power[J]. Journal of Northeast Electric Power University, 2023, 43 (3): 72- 81.
20	张杰, 王恒凤, 刘生春, 等. 基于内点法和邻域搜索解耦动态规划法的区域电网动态无功优化方法[J]. 中国电力, 2023, 56 (2): 59- 67.
	ZHANG Jie, WANG Hengfeng, LIU Shengchun, et al. Algorithm for dynamic reactive power optimization of regional power grid based on interior point method and neighborhood search decoupling dynamic programming method[J]. Electric Power, 2023, 56 (2): 59- 67.
21	杨冬锋, 冉子旭, 姜超. 面向规模化风电消纳的电-气-氢能源互联系统协同规划[J]. 东北电力大学学报, 2023, 43 (3): 91- 100.
	YANG Dongfeng, RAN Zixu, JIANG Chao. Collaborative planning of electricity-gas-hydrogen energy interconnection system for large-scale wind power consumption[J]. Journal of Northeast Electric Power University, 2023, 43 (3): 91- 100.

负载类型	功率/ W	最小时间/ s	最大时间/ s	完成确认/ 次	频次成本/ 万元
电器1	50	5	15	0.5	0.1
电器2	75	30	180	4	0.1
电视	50	30	240	1	0.5
灯1	300	5	260	2	1.0
灯2	450	5	30	2	0.6
微波炉	650	2	10	2	0.5
吹风机	1800	2	17	2	0.5
洗衣机	500	30	60	3	0.5
烘干机	2500	45	60	3	0.5
洗碗机	1200	60	90	3	0.5

负载类型	功率/ W	最小时间/ s	最大时间/ s	完成确认/ 次	频次成本/ 万元
电器1	50	5	15	0.5	0.1
电器2	75	30	180	4	0.1
电视	50	30	240	1	0.5
灯1	300	5	260	2	1.0
灯2	450	5	30	2	0.6
微波炉	650	2	10	2	0.5
吹风机	1800	2	17	2	0.5
洗衣机	500	30	60	3	0.5
烘干机	2500	45	60	3	0.5
洗碗机	1200	60	90	3	0.5

N	S	T	确定性优化时间/h	两阶段随机优化时间/h	近似动态规划时间/h
5	5	12	0.01	0.01	0.97
5	5	24	0.01	0.02	1.90
5	5	36	0.01	0.03	2.60
5	15	12	0.01	0.03	5.00
5	15	24	0.01	0.06	9.30
5	15	36	0.01	0.09	13.00
15	5	12	0.01	0.04	1.70
15	5	24	0.01	0.07	3.50
15	5	36	0.02	0.11	4.70
15	15	12	0.01	0.11	30.00
15	15	24	0.01	0.24	47.00
15	15	36	0.02	0.39	61.00

N	S	T	确定性优化时间/h	两阶段随机优化时间/h	近似动态规划时间/h
5	5	12	0.01	0.01	0.97
5	5	24	0.01	0.02	1.90
5	5	36	0.01	0.03	2.60
5	15	12	0.01	0.03	5.00
5	15	24	0.01	0.06	9.30
5	15	36	0.01	0.09	13.00
15	5	12	0.01	0.04	1.70
15	5	24	0.01	0.07	3.50
15	5	36	0.02	0.11	4.70
15	15	12	0.01	0.11	30.00
15	15	24	0.01	0.24	47.00
15	15	36	0.02	0.39	61.00
